UC0550GDL-NR

Upright Display Fridge 546L - 1 Door - Flat Glass - Lightbox

RRP $4000 ex. GST

UC0550GDL-NR

Upright Display Fridge 546L – 1 Door – Flat Glass – Lightbox

Dimensions

Height

2081mm

Depth

865mm

Width

685mm

Product Detail

Bromic’s 546L upright display fridge is designed to maximise product visibility while delivering reliable, food-safe performance in demanding commercial environments. A high-impact LED lightbox combined with vertical LED door lighting draw attention to your display and encourage impulse purchases, while six adjustable shelf tiers provide flexible merchandising options.

Certified 3M1 food-safe and fully compliant with Australian safety standards, this unit maintains consistent cooling between +2°C and +8°C even in ambient temperatures of up to 38°C. The digital controller ensures accurate temperature management and automatic defrost regulation for reliable day-to-day operation.

Heated Low-E double-glazed glass improves condensation control and energy efficiency, which contributes to the unit’s 6-star GEMS rating. Self-closing doors minimise heat transfer, and lockable front castors allow for easy positioning and secure placement making this fridge a practical, efficient solution for retail and hospitality environments.

Product Snapshot

Add to Quote

Specifications

SKU
3736260-NR
Volume
546L
Unit Weight
136kg
Width
685mm
Depth
865mm
Height
2081mm
Packaged Weight
146kg
Temperature Range
+1°C to +10°C
Ambient Temperature
38°C
Climate Class
3M1
Energy Consumption
4.34kWh/24h
GEMS Star Rating
6 stars
Refrigeration Capacity
462W
Air Circulation
Fan Forced
Refrigerant
R290
Current
2.1A
Electrical Voltage
240V
Frequency
50Hz
Power Supply
Single Phase
Plug Supplied
1 x 10A
Plug Location
Rear
Colour
Black
Internal Light
LED
Colour Temperature
6500K
Lightbox
Yes
Number of Doors
1
Door Type
Glass
Door Style
Hinged
Door Lock
Yes
Self-Closing Door
Yes
Door Swing Dimension
696mm
Total Depth of Door Open
1513mm
Number of Shelf Tiers incl. Base
6
Shelf Type
Adjustable
Shelf Dimensions
545(w) x 595(d) mm
Temp. Controller
Digital
Castors
Yes
Warranty
5 Years Bromic Extra Care Warranty - Labour and Parts

Product Features

.

LED Lightbox

High-impact LED lightbox to capture customer’s attention, as well as LED lights on the right side of the door.

Food Safe

Food safe storage with 3M1 climate class.

Precise Digital Controller

Accurate temperature control with digital controller.

Built for Australian Conditions

38°C maximum ambient temperature for consistent cooling even in extreme heat.

Easy to Move

Castors for easy placement and movement.

Easy Installation

Simple plug-and-play installation for convenience.
